China 32L82F 32″ manufacturers and suppliers

Home/ Products / LED TV / 32 /

Product Catalog Business contacts

KTC L73 Series LED TV:High-gloss and traceless + surface etching highlight the narrow-edge design.With a tower style metal base,With a blade base.With a metal backboard, solid and nice.

Product Specifications

L82 Series LED TVDifference contrast

Model 40L82F 39L82F 32L82F 24L82F

Panel size 40" 39" 32" 24"

Display parameters Backlight category DLED DLED DLED DLED
Aspect ratio 16:9 16:9 16:9 16:9
Resolution 1920*1080 1366*768 1366*768 1366*768
Viewing angle H:176°/V:176° H:178°/V:178° H:178°/V:178° H:178°/V:178°
Color 16.7M 16.7M 16.7M 16.7M
Max Brightness 260cd/m² 330cd/m² 330cd/m² 230cd/m²
Contrast ratio 5000:1 5000:1 5000:1 3000:1
Response time 9.5ms 6.5ms 6.5ms 8ms

Power waste Power ≤55W ≤55W ≤55W ≤30W
Operating voltage 100V-240VAC 60/50Hz 100V-240VAC 60/50Hz 100V-240VAC 60/50Hz 100V-240VAC 60/50Hz
Audio Power output 6W+6W 6W+6W 6W+6W 4W+4W

Specifications N.W. 6.5kg 5.5kg 4kg 2.4kg
G.W. 8.5kg 7.5kg 5kg 3.0kg

Interface type Input interface HDMI/VGA/AV-IN/TV/USB/USB2.0/USB3.0/YPbPr/PC-Audio/Audio-IN/SERVICE/Tuner/RJ-45/CI
(The above interface is optional according to the scheme) HDMI/VGA/AV-IN/TV/USB/USB2.0/USB3.0/YPbPr/PC-Audio/Audio-IN/SERVICE/Tuner/RJ-45/CI
(The above interface is optional according to the scheme) HDMI/VGA/AV-IN/TV/USB/USB2.0/USB3.0/YPbPr/PC-Audio/Audio-IN/SERVICE/Tuner/RJ-45/CI
(The above interface is optional according to the scheme) HDMI/VGA/AV-IN/TV/USB/USB2.0/USB3.0/YPbPr/PC-Audio/Audio-IN/SERVICE/Tuner/RJ-45/CI
(The above interface is optional according to the scheme)
Output interface Earphone/Audio-OUT/Video-OUT/Coaxial-OUT/SPDIF-OUT
(The above interface is optional according to the scheme) Earphone/Audio-OUT/Video-OUT/Coaxial-OUT/SPDIF-OUT
(The above interface is optional according to the scheme) Earphone/Audio-OUT/Video-OUT/Coaxial-OUT/SPDIF-OUT
(The above interface is optional according to the scheme) Earphone/Audio-OUT/Video-OUT/Coaxial-OUT/SPDIF-OUT
(The above interface is optional according to the scheme)
USB support Video/Audio/Image Video/Audio/Image Video/Audio/Image Video/Audio/Image

Packing list TV 1 1 1 1
Base 1(optional) 1(optional) 1(optional) 1(optional)
Wall bracket 1(optional) 1(optional) 1(optional) 1(optional)
Remote control 1 1 1 1
Power cord 1 1 1 1
Instructions 1 1 1 1

Remarks: KTC will provide the information as correct as possible. Product photos on this website may vary from the real products. Products information may vary from the products manual available in the market. Please use the products subjected to the specific information on the user manual. For details, please contact the related persons.

Detail Pictures of Product

Front
