Hand-Carried UltrasoundDifference contrast
-
-
Product name
Hand-Carried Ultrasound
-
Technical parameter
The following parameters are described as the main version of the animal version
-
Application scope
pig, dog, cat, cow, sheep, horse
-
Scanning Method
Intracavity probe
center frequency is 6.5MHz, frequency range is 5.0-8.5MHz, 4 frequency onversions (3/3.5/4.0/5.0MHz) (diagnosis of animal gestation, there are already probes)
-
Convex array probe
center frequency is 3.5MHz, frequency range is 3.0-5.0MHz, 4 frequency conversions (3/3.5/4.0/5.0MHz) (diagnosis of abdomen, there are already probes)
-
Line array probe
center frequency is 7.5MHz, frequency range is 5.0-10.0MHz, 4 frequency conversions (5.5/7.5/9.0/10.0MHz)
-
High-frequency convex probe
center frequency is 6.5MHz, frequency range is 5.0-8.5MHz, 4 frequency conversions (5/6.5/7.0/8.5MHz)
-
Low-frequency convex probe
center frequency is 6.5MHz, frequency range is 5.0-8.5MHz, 4 frequency conversions (3/3.5/4.0/5.0MHz)
-
Large animal rectal probe
center frequency is 7.5MHz, frequency range is 5.0-10.0MHz, 4 frequency conversions (5.5/7.5/9.0/10.0MHz)
-
PS
Probe has automatic freeze function (automatic freeze time can be preset.)
-
power supply
power input
Voltage: 100-240V
Frequency: 50/60Hz
Power: 42VA
-
power working time
Network power: ≥ 8h
frequency internal voltage ≥ 2h
-
In-output devices
USB interface
TV-OUT (Composite Video Interface)
Power line interface
-
Human-computer interaction system
Number of control panel cases 5
Touch screen
Monitor size:7 inch TFT LCD
-
Graphic information management
Movie return visit
Supports B, M mode movie playback
Support manual and automatic playback
Movie playback frames: 512 frames
-
Image storage
Static Image: JPG
Storage capacity: 1200 frames
Support: USB and other mobile storage devices
Revisit speed: 4 levels adjustable (1, 1/2, 4/1, 8/1)
-
B, M mode scan parameters
Gain
0-100dB, Step: 3dB
-
Near-field gain
0-100dB, step length: 3dB
-
Far-field gain
0-100dB, step length: 3dB
-
Dynamic Range
30-50dB, Stepping: 5dB
-
Gray-scale diagram
16 kinds of adjustable (A-P)
-
Frequency
divided into four frequency adjustable
-
Depth
The maximum depth can reach 32cm
-
Number of focal points
4 adjustable (1,2,3,4)
-
Depth of focus
The maximum depth of up to 12cm
-
Line density:
H, L two files
-
Smooth
4-speed adjustable (1,2,3,4)
-
Frame related
8-speed adjustable (0-7)
-
Edge Enhancement
4-speed adjustable (0,1,2,3)
-
Up and down
The image flips upside down
-
B/M layout
up/down
-
B/M layout ratio
50/50
-
Scan depth
large convex probe, 2.5-31cm
-
visible
Full field, low density, depth 18.5cm, frame rate 60.1 frames
-
Conventional measurement and calculation
B mode conventional measurement
Distance
Perimeter/area: ellipse, tracing
Angle
Volume: three-distance method, one-distance method, ellipse + ellipse
-
M mode conventional measurement
Slope
Heart rate
